Plough light OZZ XH1 - Rectangular / 23 cm / 60W / Ref. 27.5
Robust plow light with low and high beam for demanding conditions – automatically heated lens, turn signal, dual-color position light and switchable handedness.
Select option:
Product Faq
Robust plow light with low and high beam for demanding conditions – automatically heated lens, turn signal, dual-color position light and switchable handedness.
OZZ XH1 is a stylish and practical driving and snowplough light designed for demanding conditions. The road-approved light delivers 1700 lumens on low beam and 3100 lumens on high beam, effectively improving visibility in both work use and road driving. The low beam reaches 183 metres and the high beam 365 metres @ 1 lux, helping OZZ XH1 make the road, work area and surroundings easier to see, even in the dark. The easily changeable handedness and detachable side unit make installation and adjustment easier, making the OZZ XH1 a flexible solution for a wide range of heavy vehicles and machinery.
The automatically heated lens keeps the light functional and clear in cold, snowy and challenging weather conditions. The 5000 kelvin colour temperature produces a natural white light that is comfortable for the eyes, even during long working days. The light also features an indicator and a dual-colour position light with white and amber light, adding practicality and giving the overall design a finished look. Three-year (36-month) warranty!
Basic delivery contents
- OZZ XH1
- Power cable with DT6 connector, 500 mm
- Mounting foot
Delivery contents (2 pcs + Wiring harness)
- 2 x Basic delivery contents
- Relay cable set Purelux Pro Serie 24V, DT-6 (1 x 2 outputs)
Technical information
- Brand and model: OZZ XH1
- Intended use: As an auxiliary light in cars / work machines
- Operating voltage: 10–30V DC
- Reference number: 27.5
- Rated power: 60 W
- Power stated by the manufacturer:
- High beam: 48 W @ 12V / 48 W @ 24V
- Low beam: 22.8 W @ 12V / 24 W @ 24V
- Indicator: 12 W @ 12V / 12 W @ 24V
- Position light: 2.4 W @ 12V / 2.4 W @ 24V
- Heater: 30 W @ 12V / 30 W @ 24V
- Power consumption stated by the manufacturer:
- High beam: 4 A @ 12V / 2 A @ 24V
- Low beam: 1.9 A @ 12V / 1 A @ 24V
- Indicator: 1 A @ 12V / 0.5 A @ 24V
- Position light: 0.2 A @ 12V / 0.1 A @ 24V
- Heater: 2.5 A @ 12V / 0.9 A @ 24V
- Theoretical light output
- High beam: 4500 lm
- Low beam: 3400 lm
- Light output stated by the manufacturer:
- High beam: 3100 lm
- Low beam: 1700 lm
- Range stated by the manufacturer:
- High beam: 365 m @ 1 lux
- Low beam: 183 m @ 1 lux
- Color temperature stated by the manufacturer: 5000 K
- Mounting: Mounting foot
- Connector: DT-6
- Cable length: 500 mm
- Dimensions: 225 x 150 x 80 mm (Length x Height x Depth)
- Height with stand: 174 mm
- Other: Heated lens, high beam, low beam, indicator, white and amber position light
- Protection class: IP68, IP69K
- Approvals: EMC: ECE R10, ECE R148, ECE R149
- Warranty: 36 months
Installation guide
Manufacturer's user manual (PDF)
