Marker light Strands Firefly See Me - 10-48V / 14.5W / 102 mm

Strand's Firefly See Me is an marker light series, which consists of four different lights, especially designed for the needs of heavy equipment. The product family includes orange, red and orange and white marker light, in addition to which it includes a model with an orange marker light and an R65-approved warning light function. All lights are approved for road traffic use, so you can cover all marker lights installed on the front, sides and back of the vehicle with lights from the same series. The elegant design of the See Me lights, the slim frame and versatile mounting options ensure that the lights are suitable for any vehicle. With the help of edge lights, the vehicle or work machine will be noticed by everyone, and the visible lights increase the safety of both the driver and those moving around in the dark.

The Firefly See Me lights are easy to attach to any vehicle using the included L brackets. In addition, the frames attached to the lights in the "Click-On" style cover both the fixing screws and the edges of the light, which guarantees an unobtrusive installation and a neat end result. Thanks to the frames, the light practically becomes an integral part of the vehicle's structures, and only the essential, i.e. the light itself, remains visible. The lamps are protected against dust and water according to the IP67 classification. Wide operating voltage (10-48V) enables installation in both 12V and 24V systems. The lights are protected against radio interference according to the ECE R10 standard. Three-year (36 months) warranty!

Note! The Firefly See Me serie includes traditional R148 (R7) approved warning lights (orange, red, orange and white) as well as a marker light equipped with an R65 approved warning light function (orange). Choose the appropriate options from the product options.

Delivery content

• Strands Firefly See Me
• Power cord without connector, 1000 mm
• L-bracket
• Installation background
• Fixing screws

Specifications

• Brand and model: Strands Firefly See Me
• Purpose: As a spotlight/extreme light in vehicles and work machines
• Operating voltage: 10-48V
• Rated power: 2 W
• Light color: Orange, white or red
• Connector: Straight wires, no connector
• Dimensions: 102 x 23 x 42.5 mm (Width x Height x Depth)
  • Distance between fixing holes: 90 mm
• Power cable length: 1000 mm
• IP rating: IP67
• Approvals:
  • Orange/Red/White: EMC: ECE R10, R7
  • Orange (Warning light): EMC: ECE R10, R65 Class 2
• Installation: Click on the installation background or L-bracket
• Warranty: 36 months

Quick guide

You can find manufacturer's installation instructions by clicking here (opens in a new window).
