Auxiliary light PURELUX 9110 DRL White - Round / 23 cm / 175W / Ref. 25

 UPDATED GEN2 VERSION
 LIGHT OUTPUT 13 696 LM!
 RANGE 1039 M @ 1 lux!

GEN2 main features

• TWO POWER MODES - e-approved and UNLIMITED!
• Stylish dark optics
• Narrow beam - long range
• MEASURED LIGHT OUTPUT 13 696 lm
• AWESOME 1039 m measured range
• Orange and white parking light
• Reference number: 25

Purelux 9110 DRL White GEN2 is a version of its manufacturer's illegally powerful and very long-range 9110 UNLIMITED auxiliary light with orange and white parking light and white frame. This light offers maximum performance even for demanding drivers, and thanks to its amazing price/power ratio, it competes completely in its own class. Highly tuned electronics combined with the best Osram LEDs on the market enable a measured light output of over 13,000 lumens, while the reflector optics optimized for these LEDs form a beam of light reaching up to 1039 meters (1 lux). The user experience is crowned by an eye-pleasing color temperature of 5500 Kelvin, optimized for vehicle use, which maximizes sharpness and accuracy. As a new feature, the light has also been introduced in an e-approved lower power mode (6119 lm, 678 m @1lux) for road traffic use and poor conditions (rain, snowfall, fog).

In addition to the tremendous power, the 9110 UNLIMITED DRL White Gen2 is equipped with a stylish, orange or white parking light, which is ingeniously placed in the center of the lamp. A bright, shining small line of light spreads the light directly onto the reflector surfaces of the lamp, whereby the light radiating from the reflectors illuminates practically the entire lens, creating an eye-catching effect that will not go unnoticed by anyone. Simply stylish and unbelievably powerful, the 9110 UNLIMITED DRL White Gen2 is an excellent choice for anyone who needs an auxiliary light with unlimited light output, maximum performance and an exceptionally far-reaching beam. Thanks to the white body, it is also particularly suitable for light-colored vehicles.

Note! The same lamp is also available with a black frame: Purelux 9110 UNLIMITED DRL

There is also a stone impact protection that can be applied to the light, which can be used to widen the light beam laterally. Protection available in white and yellow.

9110 UNLIMITED DRL White differs from traditional auxiliary lights equipped with a combination light beam with its narrow light pattern, which enables the beam of 9110 to reach more than a kilometer (1 lux). In addition to the maximum range, the width of the light beam can also be easily increased by installing two or more lights in parallel, so that some of the lights can be directed to illuminate more of the edges of the road, and some can be directed straight ahead. With the power of more light, the range of the light beam also increases even more, which means that the landscape that opens up in front can be illuminated in a completely unprecedented way. The tremendous light output combined with a color temperature of 5500 Kelvin guarantees that the eyes will not be strained even on a long drive. In addition, the neutral color temperature of the lamp makes it easier to visualize terrain shapes and works better than cool shades even in bad weather conditions, such as fog and rain.

The 9110 UNLIMITED DRL's strong aluminum frame, sturdy construction and practically unbreakable Lexa polycarbonate lens ensure durability even in demanding conditions. The Purelux 9110 UNLIMITED DRL White is dust and waterproof in accordance with the IP68 protection rating, and it is also radio interference protected in accordance with the R10 standard. All in all, this is a light that lasts even when going hard, like on the front of an SUV for example! Two-year (24 months) warranty!

Valostore's comment: "The best-selling auxiliary spot light in its category has been updated! The 9110 DRL combines the wild performance known from the 9110, a really far-reaching spot light beam and a stylish two-color parking light. The version with orange and white parking light of this light cannon designed for off-road use makes it an even better option for those who want not only unlimited light output, but also stylish details. The parking light, realized in an exceptional way, illuminates practically the entire lens when it is on, which fits the image of this already rough auxiliary light perfectly!"

Basic delivery content (1 pc)

• Purelux 9110 UNLIMITED DRL White Gen2
• Mounting leg
• Fastening accessories
• Anti-vibration pad

Delivery contents (2 pcs - Complete set)

• 2 x Basic delivery contents
• Auxiliary light holder for the EU license plate
• Relay wiring kit Purelux Pro Series 12V, HD DTP, (1 pc 2-output)
• Stabilizer, 2 pcs

Delivery contents (3 pcs - Complete set)

• 3 x Basic delivery contents
• Auxiliary light holder for EU license plate, 3 mm thick HD holder, white
• Relay wiring kit Purelux Pro Serie 12V, HD DTP, (1 pc 3-output)
• Stabilizer , 4 pcs

Delivery contents (4 pcs - Complete set)

• 4 x Basic delivery contents
• Auxiliary light stand Purelux HD, for 4 lights, white
• Relay wiring kit Purelux Pro Series 12V, HD DTP, (1 x 4-output)
• Stabilizer, 4 pcs

Delivery contents (4 pcs - Complete set WRC)

• 4 x Basic delivery contents
• Auxiliary light stand Purelux WRC, for 4 lights, white
• Relay wiring kit Purelux Pro Series 12V, HD DTP, (1 x 4-output)
• Stabilizer, 4 pcs

Delivery contents (5 pcs - Complete set WRC)

• 5 x Basic delivery contents
• Auxiliary light holder Purelux WRC 5, 5 lights
• Relay wiring kit Purelux Pro Series 12V, HD DTP, (1 x 1-output, 1 x 4-output)
• Stabilizer, 6 pcs

Delivery contents (6 pcs - Complete set WRC)

• 6 x Basic delivery contents
• Auxiliary light holder Purelux WRC, 6 lights
• Relay wiring kit Purelux Pro Series 12V, HD DTP, (1 x 2-output, 1 x 4-output)
• Stabilizer, 6 pcs

Normal scratch shields can be found here

Technical information

• Brand and model: Purelux 9110 DRL White Gen2
• Purpose: As an auxiliary light in off-road vehicles / construction machines
• Operating voltage: 9-48V
• Reference number: 25
• Calculated power: 175 W
• Power consumption measured by Valostore
  • UNLIMITED: 13.48A @ 12V / 6.74A @ 24V
  • E-approved: 2.45A @ 12V / 4.89A @ 24V
• Power measured by Valostore: 161.7 W
• Light output measured by Valostore: 13696 lm
• Range measured by Valostore: 1039 m @ 1 lux / 2078 m @ 0.25 lux
• Range with more lights, measured (@ 1 lux):
  • With two: 1469 m (@ 1 lux)
  • With three: 1800 m (@ 1 lux)
  • With four: 2078 m (@ 1 lux)
• Color temperature stated by the manufacturer: 5500 K
  • Measured by Valostore: 5504 K
• Mounting: Mounting base
• Connector: DTP-2
  • The parking lights + wires are separate
• Cable length: 500 mm
• Dimensions: 230 x 90 mm (Diameter/Depth)
• Height with foot: 235 mm
• Weight: 2500 g
• IP rating: IP68
• Approvals: EMC: ECE R10, R148, R149
• Other: The light has ready-made place for stabilizer
• Warranty: 24 months
• Importer: Handshake.fi

Installation guide

Coupling

• DTP-2 connector: Auxiliary light connection (full power)
• DTP-2 connector + blue wire: Auxiliary light connection (E-approved mode)
• White: White parking light
• Yellow: Orange parking light

You can find the manufacturer's connection and installation instructions by clicking here.
