Auxiliary light Purelux 770 White - Round / 18 cm / 130W / Off-Road

• UNLIMITED = NO POWER LIMIT
• Narrow beam - long range
• MEASURED RANGE UP TO 807 m (@ 1 lux)
• MEASURED LIGHT OUTPUT 11,550 lm (+ 5%)
• Stylish white frame
• Too powerful - NOT E-Approved

The Purelux 770 White is an incredibly powerful and extremely long-range round auxiliary light, whose incredible price/performance ratio puts it on a completely different level in the 7" size range! The 770 White offers pure maximum performance, and its extremely tuned electronics combined with the best Osram LEDs on the market enable a measured light output of up to 11,550 lumens for one lamp! The reflector optics, optimized for these LEDs, form a very long light beam, which, according to the manufacturer, can reach up to 807 meters (@ 1 lux). In addition, the color tone of the lamp is optimal, pleasant to the eye, 5500K.

  The 770 White is equipped with a completely white body, which makes it particularly suitable for light-colored vehicles. Simply stylish and incredibly powerful, the 770 White is an excellent choice for anyone who needs unlimited light output, maximum performance and an exceptionally long-range beam from an auxiliary light. Due to its high power and spot-like beam, the lamp is not approved for road use.

A spreading scratch shield is also available for the light, which can be used to widen the light beam laterally. The guard is available in white and yellow .

The 770 White differs from traditional auxiliary lights with a combined beam in its narrow beam pattern, which enables the 770's beam to have a range of up to over 800 meters (1 lux). In addition to the maximum range, the beam can also be easily increased in width by installing two or more lights in parallel, allowing some of the lights to be directed to illuminate more of the edges of the road, and some to be directed straight ahead. With more lights, the beam range also increases further, meaning the landscape ahead can be illuminated in a completely unprecedented way. The tremendous light output combined with the color temperature of 5500 Kelvin ensures that the eyes are not strained even on long drives. In addition, the neutral color temperature of the lamp makes it easier to perceive terrain shapes and works better than cool tones even in bad weather conditions, such as fog and rain.

The 770 White's sturdy aluminum frame, sturdy construction, and virtually unbreakable Lexan polycarbonate lens ensure durability even in demanding conditions. The light is completely dust and waterproof according to the IP68 protection rating, and it is also radio interference-proof according to the R10 standard. All in all, this is a light that can withstand even the toughest conditions, such as on the front of an SUV! Installation is made easier by the DT-2 connector on the light's power cable and the ready-made place for a support bar on the frame. It should also be noted that the light is not E-approved, and for this reason we do not recommend installing the light on a vehicle intended for road use. The 770 is primarily intended for off-road use and closed tracks only. Two-year (24 month) warranty!

Basic delivery content

• Purelux 770 White
• Mounting foot
• Fastening accessories
• Vibration damping pad

Delivery content (2 pieces - Complete set)

• 2 x Basic delivery contents
• Auxiliary light bracket for EU license plate
• Relay wiring kit Purelux Pro Serie 12V, DT-2 (2 outputs)
• Stabilizer, 2 pcs

Delivery content (3 pieces - Complete set)

• 3 x Basic delivery content
• Auxiliary light bracket for EU license plate , 3 mm thick HD model
• Relay wiring kit Purelux Pro Serie 12V, DT-2 (3 outputs)
• Stabilizer, 4 pcs

Delivery content (4 pieces - Complete set)

• 4 x Basic delivery contents
• Auxiliary light holder Purelux HD
• Relay wiring kit Purelux Pro Serie 12V, DT-2 (4 outputs)
• Stabilizer, 4 pcs

Delivery content (4 pieces - Complete set WRC)

• 4 x Basic delivery contents
• Auxiliary light holder Purelux WRC, for 4 lights
• Relay wiring kit Purelux Pro Serie 12V, DT-2 (4 outputs)
• Stabilizer, 4 pcs

Delivery content (5 pcs - Complete set WRC)

• 5 x Basic delivery content
• Auxiliary light holder Purelux WRC, for 5 lights (max. 230 mm)
• Relay wiring kit Purelux Pro Serie 12V, DT-2 (1 pc 1-output, 1 pc 4-output)
• Stabilizer, 6 pcs

Delivery content (6 pieces - Complete set WRC)

• 6 x Basic delivery content
• Auxiliary light holder Purelux WRC, for 6 lights (max. 230 mm)
• Relay wiring kit Purelux Pro Serie 12V, DT-2 (1 pc 2-output, 1 pc 4-output)
• Stabilizer, 6 pcs

You can find standard scratch shields here

Specifications

• Brand and model: Purelux 770 White
• Intended use: As an auxiliary light in SUVs / construction machinery
• Operating voltage: 11-32 V
• Reference number: - (NOT E-approved)
• Current consumption measured by Valostore: 12.2A @ 12V / 6.1A @ 24V
• Power measured by the light bulb: 146.5 W
• Luminous efficacy measured by Valostore: 11550 lm
• Range measured by the light tower: 807 m @ 1 lux / 1614 m @ 0.25 lux
• Range with multiple lights, measured (@ 1 lux):
  • With two: 1141 m (@ 1 lux)
  • With three: 1398 m (@ 1 lux)
  • For four: 1614 m (@ 1 lux)
• Manufacturer's stated color temperature: 5500 K
  • Measured by Valostore: 5632 K
• Mounting: Mounting stand
• Connector: Deutsch DT-2
• Cable length: 500 mm
• Dimensions: 180 x 82 mm (Diameter/Depth)
  • Height with foot: 197 mm
• Weight: 1700g
• IP rating: IP68
• Approvals: ECE R10, CE, RoHS
• Warranty: 24 months
• Importer: Handshake.fi

Installation guide

General connection and installation instructions here: Additional lights installation guide. The link contains the most common installations, including using a relay wiring harness, as well as a guide to installing additional lights on the CAN bus.
